Name: Eaton - Cutler Hammer 1351E-6514
SKU: 536638

Product Details ＋

Product Attribute	Attribute Value
Body Style	Rectangular
Cable Length	2 m
Cable Type	PVC
Connection Type	Cable 5-Wire
Contact Configuration	SPDT Form C relay
Contact Rating	3A at 240V
Cord Length	79.2 Foot
Current, Switching	3 A
Height	1.81 Inch
Input Voltage	24-240 Vac, 12-240 Vdc
IP Rating	IP67
Length	3.46 Inch
Light Source	Infrared
Measurement Range	3 m
Output	SPDT
Protection	Output S/C, overcurrent and reverse polarity
Sensing Mode	Diffuse
Sensor Type	Diffuse Reflective
Series
Supply Voltage	24-240 VAC ; 12-240 VDC
Technology	Photoelectric
Type	Reflective Sensors
UPC Code	782116111671
Width	1.91 Inch

Overview

The new Enhanced versions of the Cutler-Hammer® 50 Series™ Photoelectric Sensors from Eaton's electrical business offer flexibility, durability and high optical performance in a cost-effective self-contained package. Choose from three output types, four sensing modes and three connection styles to tailor the sensor to exactly meet your needs. Sensors are available in thru-beam, reflex, polarized reflex, diffuse reflective, and clear object sensing modes. Brackets are available for easy mounting and to allow precise adjustment of sensor alignment.

Features:

High Optical Performance Models Including a 500 Foot (152 m) Thru-Beam and a 10 Foot (3 m) Diffuse Reflective Unit

Output Options Include a 3 Amp SPDT Relay

All Units Offer Light/Dark Selection

Logic Options Include ON-Delay, OFF-Delay and One-Shot Delay

Fully Potted Construction for Use in Areas Subject to Washdown, High-Shock and/or Vibration

Choice of Pre-Wired Power Cable, Built-In Microconnector, and Built-In Euro Versions. Standard Pre-Wired Cable Length Is 6 Feet (1.8 m)

Different Brackets Available Including Ball Swivel

Infrared Light Source

CSA Approved

Certified to UL Standard, UL 508
